ABLS 18 1.6 E AS

Cordless sheet metal shears up to 1.6 mm


ABLS 18 1.6 E AS
Cordless sheet metal shears up to 1.6 mm

Handy, curve-compatible cordless sheet metal shears for cutting and trimming thin sheet metal. Includes second plunger blade and fixed blade, permanent marker, painter’s tape and metre rule.

Product number: 7 130 06 62 00 0

ABLS 18 1.6 E AS

Add to Shopping Cart

Details

  • 221 m cutting capacity (in 0.8 mm sheet metal) with one battery charge (5 Ah).
  • Outstanding ergonomics through compact and simple construction for optimal mobility of the shears.
  • Four-fold reversing blade for clean and burr-free cutting with low operating costs.
  • Good curve precision with low sheet-metal distortion.
  • Perfect for trimming and cutting.
  • Unrestricted view of the cutting line.
  • Proven MultiMaster motor with outstanding performance and stability.
  • Compatible with AMPShare/Bosch Professional 18 V batteries.
  • Maximum work progress with AMPShare 18V storage batteries: COOLPACK 1.0 technology ensures a longer storage battery life compared with batteries without COOLPACK technology and therefore makes longer operating periods possible. ECP protects the storage battery against overload, overheating and total discharge.
  • Ideally equipped for every job. Mobile working with the L-BOXX system.

Technical data

Technical data
Battery voltage
18 V
Battery compatibility
Li-ion / ProCORE Li-ion
Battery interface
18 V AMPShare
Strokes
2 200 - 3 500 rpm
Cutting speed
6 - 9 m/min
Steel up to 400 N/mm²
1.6 mm
Steel up to 600 N/mm²
1.2 mm
Steel up to 800 N/mm²
1 mm
Non-ferrous metals up to 250 N/mm²
2 mm
Rad. of smallest curve
15 mm
Weight without storage battery
1.44 kg
Vibration and sound emission values
Sound pressure level LpA
74,2 dB
Uncertainty of measured value KpA
3 dB
Sound power level LWA
85,2 dB
Uncertainty of measured value KWA
3 dB
Sound peak value LpCpeak
86,0 dB
Uncertainty of measured value KpCpeak
3 dB
Vibration value 1 αhv 3-way
ah 5,2 m/s²
Uncertainty of measured value Kα
1,5 m/s²

Downloads

Product datasheet

PDF 589,60 KB

Download Product datasheet (589,60 KB)

Manual instruction

PDF 30,25 MB

Download Manual instruction (30,25 MB)

Price includes

  • 2 plunger blade and bench blade (31308072000) fitted
  • 1 socket head wrench 2 mm
  • 1 x 3 mm socket head wrench
  • 1 hand guard
  • 1 permanent marker (32133037000)
  • 1 painter's tape (32133038000)
  • 1 metre rule (18750283000)
  • 1 tool case (L-BOXX 136)

Application

Curve cuts
well suitable
Coil sections
well suitable
Interior cut-outs
suitable
Notches
suitable
suitable
well suitable

Product feature

  • Reversing blade: 4x
  • Adjustable stroke
  • Hand guard
