Cordless impact wrench/driver

Up to max. 210 Nm with brushless motor and 6-stage torque setting. For universal screwdriving applications including self-drilling screwdriving.

More Details

Product number: 7 115 11 61 00 0

Buy Demonstration
Buy Demonstration

ASCD 18-200 W4 AS

Add to Shopping Cart

Details

  • For extreme precision work: The ASCD 18-200 W4 AS with electronic torque setting (6 levels) prevents screw heads from shearing off.
  • Brushless motor with 30% higher efficiency and long service life.
  • 1/4” hexagon socket tool mounting for holding bits and socket wrench inserts.
  • 10% more torque in reverse running to loosen screws which are extremely tight.
  • Robust solid metal impact gear.
  • Contact guard on gearbox head.
  • Compact design.
  • 700 screw connections (M18) with one battery charge (ProCORE 4 Ah).
  • Bit and belt holder on the side for ergonomic and flexible handling.
  • Compatible with Bosch Professional 18 V batteries (available since 2008) and AMPShare batteries.
  • Maximum work progress with AMPShare 18V ProCORE batteries: COOLPACK 2.0 technology delivers a 135% longer battery life. State-of-the-art cell technology and intelligent battery management deliver 87% more power than with conventional batteries. “Electronic Cell Protection” (ECP) protects the battery from overload, overheating and total discharge.
  • Ideally equipped for every form of use. Mobile working with the L-BOXX system.

Technical data

Technical data
Battery voltage
18 V
Battery compatibility
Li-ion / ProCORE Li-ion
Battery interface
18 V AMPShare
Motor
brushless
Speed, no load
0 - 1 500 rpm
Impacts
0 - 3 000 rpm
Max. torque
210 Nm
Torque levels
6
Tool Holder
1/4 in hexagon socket
Wood screw Ø
8 x 200 mm
Weight without storage battery
1.20 kg
Vibration and sound emission values
Sound pressure level LpA
96,1 dB
Uncertainty of measured value KpA
3 dB
Sound power level LWA
104,1 dB
Uncertainty of measured value KWA
3 dB
Sound peak value LpCpeak
118,1 dB
Uncertainty of measured value KpCpeak
3 dB
Vibration value 1 αhv 3-way
αh 13,4 m/s²
Uncertainty of measured value Kα
1,5 m/s²

Downloads

Product datasheet

PDF 998,35 KB

Download Product datasheet (998,35 KB)

Manual instruction

PDF 35,04 MB

Download Manual instruction (35,04 MB)

Manual instruction

PDF 35,94 MB

Download Manual instruction (35,94 MB)

Price includes

  • 1 belt clip
  • 1 magnetic bit storage
  • 1 tool case (L-Boxx 136)
